ITEM NO
|
HX-5W
|
Solar Cell
|
125MONO
|
Maximum Power(W)
|
5
|
Optimum Power Voltage(Vmp)
|
6
|
Optimum Operatige Current(Imp)
|
0.91
|
Open Circuit Voltage(Voc)
|
7.08
|
Short Circuit Current(Isc)
|
0.83
|
Size of Module(mm)
|
195*195*2.5mm
|
Temperature Coefficients of Isc(%)℃
|
0.065+/-0.015%/°C
|
Temperature Coefficients of Voc(%)℃
|
_(22.3+/0.1)mv°C
|
Temperature Coefficients of Pm(%)℃
|
_(0.5+/-0.05)/°C
|
Temperature Coefficients of Im(%)℃
|
+0.1/°C
|
Temperature Coefficients of Vm(%)℃
|
-0.38/°C
|
Temperature Range
|
-40°C to +85°C
|
Tolerance Wattage(e.g.+/-5%)
|
±3%
|
Weight Per Piece(KG)
|
0.2
|
Junction Box Type
|
Pass the CE,FCC,IEC Certificate
|
Cell Efficiency (%)
|
19%
|
FF (%)
|
70-72%
|
